Hyundai i30 (PD) 2018-2025 Owner's Manual

Hyundai i30 (PD) 2018-2025 Owner's Manual

Oners Manual for third generation (PD) Hyundai i30, model years 2018-2025. This manual applies to all models of Hyundai i30 and includes descriptions and explanations of optional as well as standard equipment. As aresult, some of the equipment operating descriptions referred to may not apply to the particular vehicle with which this manual is supplied. Your Owner’s Manual will introduce you to the features and operation of your new i30. To become familiar with your new Hyundai, so that you can fully enjoy it, read this Owner’s Manual carefully before driving your new vehicle.

Hyundai i30 (PD) 2018-2025 Owner's Manual

Your vehicle at a glance

..

Other information:

Hyundai i30 (PD) 2018-2025 Service Manual: Instrument Cluster


Components and components location Components TFT LCD Cluster (Standard) TFT LCD Cluster (7Inch) Connector Pin Information Connector Pin Information No. Description No. Description 1 Ground 21 Trip switch (-) 2 Illumination (-) 22 Trip switch 1 (+) 3 Rheostat switch (Down)_Input 23 Trip switch 2 (+) 4 Rheostat switch (Up)_Input 24 M/T N switch 5 Dentent 25 Driver mode switch 6 P 26 - 7 R 27 - 8 N 28 Low washer level sensor 9 D 29 M-CAN (Low) 10 S 30 M-CAN (High) 11 Immobillizer 31 - 12 Vehicle speed_Output 32 C-CAN (High) 13 Alternator_Input 33 C-CAN(Low) 14 Fuel sender (+)_Input 34 - 15 - 35 - 16 Fuel sender (-)_Input 36 - 17 Water separator (+) 37 Ground 18 Airbag (+)_Input 38 - 19 Oil press switch (-)_Input 39 IGN 1 20 Tail_input 40 Battery (+) Schematic diagrams Circuit Diagram TFT LCD Cluster (Standard) TFT LCD Cluster (7Inch) Description and operation Description Communication Network Diagram Abbreviation Expalnation ECM Engine Control Module TCU Transmission Control Unit MDPS Motor Driven Power Steering AEB Autonomous Emergency Braking LKAS Lane Keeping Assist System FPS Fuel Pump Control module RR CAMERA Rear View Carmera VACUUM Vacuum Pump CLUSTER Cluster Module ACU Airbag Control Unit DATC Dual Automatic Temp Control MTC Temp Control OCS Occupant Classification System VDC Vehicle Dynamic Control BSD Blind Spot Detection AMP Amplifier AVN Head Unit (Audio / AVN) SMK Smart Key Unit WPC Wireless Power Charger IMS Integrated Memory System DDM Driver Door Module ADM Assist Door Module BCM Body Control Module B-CAN Body Controller Area Network P-CAN Powertrain Controller Area Network M-CAN Multi media Controller Area Network C-CAN Chassis Controller Area Network Cluster Variant Coding As we have more options (ESC, MDPS etc...

Hyundai i30 (PD) 2018-2025 Owner's Manual: Sunvisor


To use a sunvisor, pull it downward. To use a sunvisor for a side window, pull it downward, unsnap it from the bracket (1) and swing it to the side (2). To use the vanity mirror, pull down the sunvisor and slide the mirror cover (3). Use the ticket holder (4) to hold tickets...

Categories

Power windows

Hyundai i30. Power windows

(1) Driver’s door power window switch
(2) Front passenger’s door power window switch
(3) Rear door (right) power window switch
(4) Rear door (left) power window switch
(5) Window opening and closing
(6) Automatic power window
(7) Power window lock switch
